5-00074
ExactFit Radiator
MAP
$947.00
ExactFit Griffin aluminum radiator with a 27.38" x 22.61" downflow design and 2-row MegaCool core, built for efficient cooling in applications under 800 HP.
Click to zoom
Engineering Drawing, actual product may vary
Key Specs
Core Size23.94" × 17.00"
Overall Size27.38" × 22.61"
Rows2
FlowDownFlow
Max HP800
Engine Side Brackets
Upgrade to Combo Unit
Part No. CU-00074
Get the radiator, fans, shroud & cap as one complete package.
$1,297.00
MAP
View ComboUnit Details
Dimensions
Overall Width27.38"
Overall Height22.61"
Overall Thickness3.00"
Core Width23.94"
Core Height17.00"
Core Thickness2.68"
Configuration
InletTop Passenger, 1.5"
OutletBottom Driver, 1.75"
Cap IncludedNo
Cooling
Flow TypeDownFlow
Rows2
Tube Size1.25"
Core Area407 sq in
MaterialAluminum
FinishNatural
Est. Max HP Rating800
Transmission
TransmissionManual
Application
Engine FamilyAMX/AMC "ALL"
Vehicle Fitments (35) Show All
| Year | Make | Model | Engine | Transmission |
|---|---|---|---|---|
| 1970 | AMC | Ambassador | Manual | |
| 1971 | AMC | Ambassador | Manual | |
| 1972 | AMC | Ambassador | Manual | |
| 1973 | AMC | Ambassador | Manual | |
| 1974 | AMC | Ambassador | Manual | |
| 1970 | AMC | Gremlin | Manual | |
| 1971 | AMC | Gremlin | Manual | |
| 1972 | AMC | Gremlin | Manual | |
| 1973 | AMC | Gremlin | Manual | |
| 1974 | AMC | Gremlin | Manual | |
| 1969 | AMC | Hornet | Manual | |
| 1970 | AMC | Hornet | Manual | |
| 1971 | AMC | Hornet | Manual | |
| 1972 | AMC | Hornet | Manual | |
| 1973 | AMC | Hornet | Manual | |
| 1974 | AMC | Hornet | Manual | |
| 1975 | AMC | Hornet | Manual | |
| 1976 | AMC | Hornet | Manual | |
| 1977 | AMC | Hornet | Manual | |
| 1967 | AMC | Javelin | Manual | |
| 1968 | AMC | Javelin | Manual | |
| 1969 | AMC | Javelin | Manual | |
| 1970 | AMC | Javelin | Manual | |
| 1971 | AMC | Javelin | Manual | |
| 1972 | AMC | Javelin | Manual | |
| 1973 | AMC | Javelin | Manual | |
| 1974 | AMC | Javelin | Manual | |
| 1971 | AMC | Matador | Manual | |
| 1972 | AMC | Matador | Manual | |
| 1973 | AMC | Matador | Manual | |
| 1974 | AMC | Matador | Manual | |
| 1975 | AMC | Matador | Manual | |
| 1976 | AMC | Matador | Manual | |
| 1977 | AMC | Matador | Manual | |
| 1978 | AMC | Matador | Manual |
